JVS & ACE Electric Internal Vibrators
Interchangeability is VIBCO's solution to making the tough job easy.
• Heavy Duty Universal Motor
• Interchangeable Heads
• Interchangeable Flexible Shafts
• Reversible Shafts for Double Life
• Shafts Available Up to 21 Ft.
3 EASY STEPS TO SELECT
1. MOTOR OPTIONS: You have 2 motors to choose from; Model JVS 1.5 HP or Model ACE 2.5 HP.
2. HEAD SIZE OPTIONS: 3/4" - 1" head diameter use: thinnest prestressed sections of burial vaults, manholes,etc.
1-1 /4" - 1-112" head diameter use: thin prestressed sections manholes, pipes, septic tanks, etc.
1-3/4" head diameter use: the most versatile and general purpose head; ideal for floors, slabs, walls, columns, bridge decks, railings,
2" head diameter use: all around size capable of handling stiff low slump mixes, heavy open forms, large foundations, retaining walls/
2-1 /2" head diameter use: enough force for the stiffest low slump heavy bridge work, etc.
3. FLEXIBLE SHAFT SELECTION:
Since the motor is carried at waist height when wearing the shoulder strap, choose the strap length of appropriate waist height plus form depth. Each Motor has 3 different lengths to choose from
